Galeon 510 Sky

Galeon 510 Sky

The SKYDECK model is a natural evolution of the award-winning 500 FLY. Sharing the hull design and all the great features that made the 500 so popular, it manages to take it a step further with its innovative top deck design. The ability to combine the advantages of the classic flybridge and the distinct, sporty look of the hardtop are unique to the Galeon SKYDECK line, and earned this model a 2016 World Yacht Trophy award for Innovative design at the Cannes Yachting Festival.

The 510 is fitted with a spectacular glass sunroof over the helm station as well as a top deck with sundecks and extra steering, that can be covered with a soft roof when necessary. Three cockpit layouts are available: full-sized garage with a sun pad on top, a classic L-shaped sofa and crew cabin setup or the innovative roto-seat option that includes a compact garage. All options allow for the outstanding Beach Mode to be fitted, extending the cockpit width to an incredible six meters.

TECHNICAL SPECIFICATIONS

DIMENSIONS
  • Length overall 53’ 02” / 16.20 m
  • Hull length 47’ 05” / 14.44 m
  • Beam 14’ 08” / 4.46 m
  • Dry weight 50,155 lb / 22,750 kg
  • Maximum load weight 59,568 lb / 27,020 kg
  • Draft (maximum) 55” / 140 cm
  • Height (including mast light) 19’ 00” / 5.80 m
PERFORMANCE
  • Volvo Penta 2x D11 670 (2x 670 hp / 493 kW) Diesel engines
  • V-Drive Transmission
  • Propellers (NiBrAl)
  • Propellers Shafts (Stainless Steel)
  • Electronic Vessel Control System
  • Exhaust,wet
  • Hydraulic steering system
  • Rudder (Bronze)
    Trim tab, hydraulic with indicators
TANKS
  • FUEL CAPACITY 475 GAL / 1,800 L
  • WATER CAPACITY 171 GAL/ 650 L
  • BLACK WATER CAPACITY 63 GAL / 240 L

EXTERIOR

INTERIOR
